Description
Table
Table size - 1270 x 254 or 1370 x 254 mm
T-slot (W x No. x Dist.) - 16 x 3 x 63 mm
Travel
Longitudinal travel (X axis) - 776 mm
Cross travel (Y axis) - 400 mm
Knee travel - 406 mm
Ram travel - 480 mm
Spindle Spindle speeds - 8 steps 80-2720 rpm
60-4200 / 0-4200
Spindle taper - NST 30 or R8
Quill travel - 127 mm
Quill feedrate - 0.04 / 0.08 / 0.15 mm/rev
Spindle motor -3HP
Quill diameter - Ø86
Head tilt - 45° (Head swivel 90°)
Spindle nose to top of table - 80-483 mm
Spindle center to column - 180-515 mm
Electric
Coolant pump - 1/8 HP - 2P
Size and Weight
Machine dimensions - 1750 x 1550 x 2200 mm
Packing dimensions - 1500 x 1650 x 1980 mm
Net weight - 1350 kgs
HIGH QUALITY PERFORMANCE FOR 2 / 3 / 4 SERIES:
-Major castings are manufactured from high quality Meehanite cast iron, completely annealed and stress relieved for deformation free performance.
-The overarm is ruggedly constructed and exhibits exceptional stability when performing heavy cutting.
-Square slideways on Y, Z-axis (for 4V series) way surfaces are hardened and precision ground assuring maximum rigidity and maintaining high accuracy in heavy cutting.
-Table slideways, and top and bottom surfaces are tempered and hardened.
-T-slots on table are also precision ground to upgrade accuracy on reference planes.
-X, Y-axis slideways are coated with Turcite-B for smooth traverse and wear-resistance.
-X, Y-axis feed screws are hard chrome plated for increasing wear-resistance capability and service life.
-The major cast iron of FC-30 and FCD-45 is high tensile material (MEEHANITE), it is annealed for stress relieving, featuring anti-wearness and deformation free.
-Automatic lubrication system provides lubrication to X, Y, Z-axis slideways and feed screws. Lubrication frequency and oil flow are adjustable. (Optional)
-Power feed units for X, Y-axis are available upon request (optional).
Table size - 1270 x 254 or 1370 x 254 mm
T-slot (W x No. x Dist.) - 16 x 3 x 63 mm
Travel
Longitudinal travel (X axis) - 776 mm
Cross travel (Y axis) - 400 mm
Knee travel - 406 mm
Ram travel - 480 mm
Spindle Spindle speeds - 8 steps 80-2720 rpm
60-4200 / 0-4200
Spindle taper - NST 30 or R8
Quill travel - 127 mm
Quill feedrate - 0.04 / 0.08 / 0.15 mm/rev
Spindle motor -3HP
Quill diameter - Ø86
Head tilt - 45° (Head swivel 90°)
Spindle nose to top of table - 80-483 mm
Spindle center to column - 180-515 mm
Electric
Coolant pump - 1/8 HP - 2P
Size and Weight
Machine dimensions - 1750 x 1550 x 2200 mm
Packing dimensions - 1500 x 1650 x 1980 mm
Net weight - 1350 kgs
HIGH QUALITY PERFORMANCE FOR 2 / 3 / 4 SERIES:
-Major castings are manufactured from high quality Meehanite cast iron, completely annealed and stress relieved for deformation free performance.
-The overarm is ruggedly constructed and exhibits exceptional stability when performing heavy cutting.
-Square slideways on Y, Z-axis (for 4V series) way surfaces are hardened and precision ground assuring maximum rigidity and maintaining high accuracy in heavy cutting.
-Table slideways, and top and bottom surfaces are tempered and hardened.
-T-slots on table are also precision ground to upgrade accuracy on reference planes.
-X, Y-axis slideways are coated with Turcite-B for smooth traverse and wear-resistance.
-X, Y-axis feed screws are hard chrome plated for increasing wear-resistance capability and service life.
-The major cast iron of FC-30 and FCD-45 is high tensile material (MEEHANITE), it is annealed for stress relieving, featuring anti-wearness and deformation free.
-Automatic lubrication system provides lubrication to X, Y, Z-axis slideways and feed screws. Lubrication frequency and oil flow are adjustable. (Optional)
-Power feed units for X, Y-axis are available upon request (optional).
