PUR Roll Laminating Machine Aluminum Foil Sticking Machinery PUR Coating Machine
BSM Machinery Trading Sdn BhdType: Sale
PUR steel laminating machine is stick adornment material such as PVC,PE,PET ,PETG on the whole roll steel ,galvanized sheet ,aluminum plate and so on ,it can be bended ,punched after laminating curing .
Description
PUR steel laminating machine is stick adornment material such as PVC,PE,PET ,PETG on the whole roll steel ,galvanized sheet ,aluminum plate and so on ,it can be bended ,punched after laminating curing .The finished production mostly used in building material .
①. Type of glue:PUR
②. Type of glue spread:Roller Coating
③. voltage:380V
④. steel width:1220mm
⑤. PLC Automatic tracking the cutting
⑥. Feeding power:12KW
⑦. Heating power:60KW
⑧. Electric lift
⑨. hydraulic cylinder
⑩. Front Feeding location
Should you're in need of the discount pur roll laminating machine aluminum foil sticking machinery pur coating machine, welcome to buy with our manufacturers and suppliers in China. We offer one year warranty for all the products made in China. And the customized service is also offered if you need.
Model specification :240x1350mm
Board lenth: above 600mm
Board width:1220mm
board thickness: coil 0.3-1.5mm ,sheet:1.8-3.5mm
Feeding speed: 1-25m/min
Motivity power: 24kw
Heating power:63kw
Film width: 1280mm
Overall dimensions:36000X2130X1800MM
Machine weight: 15000kg
①. Type of glue:PUR
②. Type of glue spread:Roller Coating
③. voltage:380V
④. steel width:1220mm
⑤. PLC Automatic tracking the cutting
⑥. Feeding power:12KW
⑦. Heating power:60KW
⑧. Electric lift
⑨. hydraulic cylinder
⑩. Front Feeding location
Should you're in need of the discount pur roll laminating machine aluminum foil sticking machinery pur coating machine, welcome to buy with our manufacturers and suppliers in China. We offer one year warranty for all the products made in China. And the customized service is also offered if you need.
Model specification :240x1350mm
Board lenth: above 600mm
Board width:1220mm
board thickness: coil 0.3-1.5mm ,sheet:1.8-3.5mm
Feeding speed: 1-25m/min
Motivity power: 24kw
Heating power:63kw
Film width: 1280mm
Overall dimensions:36000X2130X1800MM
Machine weight: 15000kg
