Optimarc CV500P
Lincoln Energy Sdn BhdType: Sale
The digitally controlled OPTIMARC® CV 500P provides constant voltage (CV) output for heavy duty welding applications and delivers superior welding performance and faster response to changes at the arc.
Description
The digitally controlled OPTIMARC® CV 500P provides constant voltage (CV) output for heavy duty welding applications and delivers superior welding performance and faster response to changes at the arc. It is an ideally suited for MIG/MAG and Flux Cored arc welding processes. Pulse welding of carbon and stainless steel could attain high-quality welding performance.
OPTIMARC® CV 500P could achieve high input power factor ratings for real savings on your electric bills and decrease your welding costs. The welding system including LWFTM wire feeder could provide output control with optimum spot to meet the need of arc performance and welding quality from customers.
OPTIMARC® CV 500P is ideal power source for industrial manufacturing such as steel structure, engineering machinery, ship manufacturing, petrochemical.
Synergic function, preset current is matched with voltage automatically
Unique low power consumption design with 85% efficiency and 0.94 power factor
Adjustable arc control, welder can choose soft arc or hard arc based on each mode
Fast arc response, even output control, uniform appearance, superior arc performance and weld penetration control.
Digital Meters-accurate weld parameter readings-weld parameter readings retained till welding ends-auto fault diagnostic display
Both voltage and current are pre-settable
Precise control, comparing with conventional SCR power source, precise control over arc stability could help realize less spatters and better bead.
“Made To Last” PC Boards-“Trayed & Potted” PCB’s filled with epoxy, double locked wiring harness Connectors, and environmentally protected connectors. Sensibly located to provide maximum protection from the environment
IP 23 Ratings-designed for harsh environment
Product Name OPTIMARC® CV500P
Input Power 380V~415V (±10%) 3/50 or 60 Hz
Rated Output Current/ Duty Cycle 500A/39V/60%, 390A/33.5V/100%
Output Range 16-39V, 50-500A
Input Power @Rated Output (KW) 23@60%
Dimensions H×W×D (mm) 540 x 340 x 800
Net Weight (Kg) 47
Process Pulse MIG / MAG
MIG / MAG
FCAW-GS / SS
Input power 380~415(±10%) /3/50/60
OPTIMARC® CV 500P could achieve high input power factor ratings for real savings on your electric bills and decrease your welding costs. The welding system including LWFTM wire feeder could provide output control with optimum spot to meet the need of arc performance and welding quality from customers.
OPTIMARC® CV 500P is ideal power source for industrial manufacturing such as steel structure, engineering machinery, ship manufacturing, petrochemical.
Synergic function, preset current is matched with voltage automatically
Unique low power consumption design with 85% efficiency and 0.94 power factor
Adjustable arc control, welder can choose soft arc or hard arc based on each mode
Fast arc response, even output control, uniform appearance, superior arc performance and weld penetration control.
Digital Meters-accurate weld parameter readings-weld parameter readings retained till welding ends-auto fault diagnostic display
Both voltage and current are pre-settable
Precise control, comparing with conventional SCR power source, precise control over arc stability could help realize less spatters and better bead.
“Made To Last” PC Boards-“Trayed & Potted” PCB’s filled with epoxy, double locked wiring harness Connectors, and environmentally protected connectors. Sensibly located to provide maximum protection from the environment
IP 23 Ratings-designed for harsh environment
Product Name OPTIMARC® CV500P
Input Power 380V~415V (±10%) 3/50 or 60 Hz
Rated Output Current/ Duty Cycle 500A/39V/60%, 390A/33.5V/100%
Output Range 16-39V, 50-500A
Input Power @Rated Output (KW) 23@60%
Dimensions H×W×D (mm) 540 x 340 x 800
Net Weight (Kg) 47
Process Pulse MIG / MAG
MIG / MAG
FCAW-GS / SS
Input power 380~415(±10%) /3/50/60
