NDP Standard Pump Series : Air Switching Type
Newera Tools & Machinery (M) Sdn BhdType: Sale
This yamada work horse is compact and has very competitive performance and many other features.
This pump is popular in many industries.
Description
This yamada work horse is compact and has very competitive performance and many other features.
This pump is popular in many industries.
Specification
| Nominal port size | 1″（25A） | |
| Connection to liquid | Inlet | Flange JIS 10K 25A or equivalent ※ |
| Outlet | ||
| Air connection | Inlet | Rc3/8 (with an air cock) |
| Exhaust | Rc3/4 (Equipped with a muffler) 0 | |
| Air supply pressure range | 0.2～0.7MPa | |
| Maximum discharge pressure | 0.7MPa | |
| Discharge volume/cycle | Rubber diaphragm type: 600mL | |
| Fluorocarbon resin diaphragm type: 500mL | ||
| Limit of slurry | 3mm or less | |
| Weight | NDP-25BA□：13.0kg NDP-25BS□：20.0kg NDP-25BF□：20.0kg NDP-25BP□：11.0kg NDP-25BV□：13.5kg |
|
Exploded view and Parts list
|
Model name |
NDP25-BA□ |
NDP25-BS□ |
NDP25-BF□ |
NDP25-BP□ |
NDP25-BV□ |
|
Ball valve |
NDP-25B□□・・・Same material as that of a diaphragm |
||||
|
Valve seat |
SMS1025 |
SUS316 |
PPG |
PVDF |
|
|
Valve guide |
A5056 |
SCS14 |
|||
|
Center disk |
NDP-25BA□・・・A5056 NDP-25BP□・・・PPG(SUS304) NDP-25BV□・・・PVDF(SUS304) |
||||
SUS304 is insert material.
★Initial self-suction lift is:
NDP-25B□ T: 2m Other NDP-25B□□pumps: 5m
 |
The maximum applicable pressure for the body wetting part of a resin type(BP□, BV□) depends on the liquid temperature. Be sure to check the chart showing the relation between the liquid temperature and maximum applecable pressure. |
Exploded view and Parts list
| Material of the main body (wetted part) | Material of a diaphragm | |||
|
C：Neoprene (CR) |
N：Buna N (NBR) |
E：EPDM |
V：Viton® |
|
|
A : Aluminumalloy |
NDP-25BAC （851328） |
NDP-25BAN （851329） |
||
|
S : Stainless steel |
NDP-25BSC （851338） |
NDP-25BSN （851339） |
||
|
F：Cast iron |
NDP-25BFC （851333） |
NDP-25BFN （851334） |
||
|
P : Polypropylene |
NDP-25BPC-FL （853835） |
NDP-25BPN-FL （853836） |
NDP-25BPV-FL |
|
|
P : Polypropylene |
||||
|
V：Polyvinylidene fluoride |
― |
― |
NDP-25BVV-FL |
|
|
V：Polyvinylidene fluoride |
― |
― |
||
※Available on request
| Material of the main body (wetted part) |
Material of a diaphragm |
|||
|
T：PTFE |
H：Hytrel® (TPEE) |
S：Santoprene® (TPO） |
H/T |
|
|
A : Aluminumalloy |
NDP-25BAH/T (851878) |
|||
|
S : Stainless steel |
NDP-25BSH/T (851879) |
|||
|
F：Cast iron |
NDP-25BFH/T (851880) |
|||
|
P : Polypropylene |
||||
|
P : Polypropylene |
||||
|
V：Polyvinylidene fluoride |
― | ― | ||
|
V：Polyvinylidene fluoride |
― |
― |
||
※Available on request
