MESSER Tornado Series BD and BSD Cylinder Pressure Regulator
Type: Sale
HEAVY DUTY DOUBLE STAGE CYLINDER PRESSURE REGULATORS WITH OUTLET PRESSURE-GAUGE
Description
TORNADE Series BD and BSD
HEAVY DUTY DOUBLE STAGE REGULATORS WITH PRESSURE-GAUGE
The TORNADO double stage regualtor, first stage piston-loaded and second stage spring-loaded, with pressure gauge is a time and industry proven design that has evolved from more than 100 years of Messer German engineering experience and technology to ensure the accurate control of industrial gases with minimum outlet pressure fluctuations and stable outlet pressures.
TORNADO regulators series BD and BSD are visibly strong, no nonsense, durable construction that sets the standard for pressure regualtors used the most up-to-date production and testing facilities to ensure a reliable, versatile, affordable, high performance regulator.
HEAVY DUTY DOUBLE STAGE REGULATORS WITH PRESSURE-GAUGE
The TORNADO double stage regualtor, first stage piston-loaded and second stage spring-loaded, with pressure gauge is a time and industry proven design that has evolved from more than 100 years of Messer German engineering experience and technology to ensure the accurate control of industrial gases with minimum outlet pressure fluctuations and stable outlet pressures.
TORNADO regulators series BD and BSD are visibly strong, no nonsense, durable construction that sets the standard for pressure regualtors used the most up-to-date production and testing facilities to ensure a reliable, versatile, affordable, high performance regulator.
- Designed according to the most current internationally recognizedstandards EN ISO, BSP, CGA, NFE and AS.
- Manufactured under the quality management of EN ISO 9001.
- 100% tested before despatch
- Compact and economically designed double stage construction.
- The forged brass body and housing cao machined from class "A" brass bar stock to obtain maximum strength and serviceability.
- First stage piston type regulator and second stage 2" disphragm regualtor provide performance of both stages, are fatigue resistant, and will give long, troble-free service.
- Economically designed and colour coded adjusting handwheel
- Fire-retardant valve material.
- Soft valve seat for longer life span.
- Inlet and outlet pressure gauge with dual scale (bar and psig)
- Replaceable sintered inlet filter prevents foreign matter entering regulator, reduces velocity of gas, prevents high pressure oxygen heat spots.
- Inlet and outlet pressure gauge with dual scale (bar and psig).
- External pressure relief valve prevents damage to disphragm and ensures operator safety.
- Unique, interfrated outlet pressure locking device.
- Intergrated outlet pressure restriction prevents damage to diaphragm.
- Outliet pressure stability permits a steady flow of gases.
- Single modular component.
- Reduced maintenance and downtime due maintenance-free technology.
- Precision engineered for optimum performance and long life.
- Weight: 2, 13 kg / 4 Ibs 11 oz
