Floor Hinge
PRODUCT CODE: CKS-840 (15NM / 20NM / 25NM / 28NM)


Spring strength	1	2	3	4
Closing force approx (Nm.)	15	20	25	28
Standard and door width	800	1000	1200	1300
Closing speed variable by value adjustment	√	√	√	√
Door weights up to (kg)	75	100	115	130
Hold-open point  (90°) or non-hold open	√ O	√ √	√ √	√ O
Weight approx (kg)	6.0	6.0	6.0	6.0
dimensions (mm) Length Width Height	320 130 42	320 130 42	320 130 42	320 130 42

√ Yes
O Option

Adjustment in cement case: Length x 10mm, horizontal x 5mm, height x 15mm

Maximum Frameless Glass Door Dimension For CKS Floor HInge (CKS-840)



Spring Strength	15Nm	20Nm	25Nm	28Nm
Max door width (W) mm	800	1000	1200	1300
Max door weight (KG)	75	100	115	130

*Remark: Please consult product manufacturer for maximum height (H) of frameless glass door



*Above mentioned reference are to be a general design guide only. Individual project requirements will dictate final glass specification and thickness as per different standard requirement.

3 YEARS PRODUCT WARRANTY
