Hight Duty Industrial Applications : Suitable for military industry, Steel structure factory, Petroleum Industry, Shipbuilding, Other large enterprise, Maintenance
Processes : MMA
Benefit : Water Resistance

Technical Data :
Power supply : 1~220/230/240V + 10%
Frequency : 50/60 (Hz)
Rated Input current : 46A
Rated Input Power : 6.8KW
Welding Current Range : 10-200A
No Load Voltage : 74V
Duty cycle (40C 10min) : 30% 200A
                                              : 60% 145A
                                              : 100% 110A

Efficiency : 85%
Power Factor : 0.7
Net Weight : 4.5 Kg
Dimensions : 290x135x220 mm
Electrode Diameter : 1.6 - 5.0

Extra Function : Automatic arc force, hot start & anti-stick for greater control and ease of use.

Weight : Extrenely low weight and versatility.

Protections : Equipped with temperature, voltage and current sensor for high protection.

Generator friendly : Designed to work with diesel generators and to ovoid failures due to its voltage spikes.

Digital display : Digital current display meter for accurate pre-setting and feed back of welding parameters & output.
