Description:
1.Items included in the equipment:

• LSP-L800 deburring machine
• A set of imported vacuum adsorption system (original import, safe and efficient, saving energy)
• One set of 7.5KW vacuum dust collector

2.Equipment main processing range.
This equipment is a combination models that consists of dry sand belt and four sets of universal sand roller brush. Mainly used to handle the deburring at the edge of the workpiece, and the hole and the processing of the surface of the metal sheet, such as drawing, descaling and polishing. The burrs generated in the process of stamping, shearing, laser cutting, plasma cutting, flame cutting, etc. It can remove the burrs in one time, so that all the edges and holes of the workpiece can achieve a small R arc effect, and the machining process is safe and reliable, so that the workpiece achieve perfect quality.

3.Machine working principle:

The equipment first removes large burrs such as slag particles on the surface of the workpiece through a set of abrasive belt stations, and then uses the combination of four sets of universal sanding roller brushes(the adjacent two sand brush are rotated forward and backward, and combination of sand brush rotate forward)to remove the burrs at the edge of the workpiece and inside the holes and generate a uniform R angle (the R angle can be achieved by selecting different processes and abrasive belts), and the through-machining process will not destroy the dimensional accuracy of the workpiece. At the same time, the belt working station and the sanding brush working station can also run independently. the belt running station can realize the processing of drawing, polishing, descaling and de-slaging of the surface of the metal sheet; the sand brush can be operated independently to achieve 360 degrees without dead angle deburring.


The conveying system is equipped with vacuum negative pressure adsorption to fix the workpiece, and the conveying system is frequency-controlled.


Equip with vacuum dust collector handles grinding dust to achieve environmentally friendly production and provides a good working environment for workers.
