Description
Features：
1.non-high-frequency arc starting, easy to carry;★
2.leading advanced arc control technology, easy to cut metal mesh or continuous metal; ★;
3.can be any curve cutting sheet metal;
4.professional excellence plasma cutting performance, and for carbon steel, stainless steel, aluminum and copper materials cutting quality is superior;
5.is widely used and steel structure, manufacturing, vehicle maintenance, etc;
6.Optimization of the cutting torch cooling, significantly extend parts life;
7.the use of air pressure regulator (buck), can be applied to the case of high external gas pressure;
8.continuously adjustable cutting current, accurate and intuitive;
9.built-in overcurrent, overheating, overvoltage, undervoltage protection circuit, safe operation;
★Some models do not have some of these features, please read the product manual
1.non-high-frequency arc starting, easy to carry;★
2.leading advanced arc control technology, easy to cut metal mesh or continuous metal; ★;
3.can be any curve cutting sheet metal;
4.professional excellence plasma cutting performance, and for carbon steel, stainless steel, aluminum and copper materials cutting quality is superior;
5.is widely used and steel structure, manufacturing, vehicle maintenance, etc;
6.Optimization of the cutting torch cooling, significantly extend parts life;
7.the use of air pressure regulator (buck), can be applied to the case of high external gas pressure;
8.continuously adjustable cutting current, accurate and intuitive;
9.built-in overcurrent, overheating, overvoltage, undervoltage protection circuit, safe operation;
★Some models do not have some of these features, please read the product manual
| Input power voltage(V) | Three phase 380V±15% | ||
| frequency(HZ) | 50/60 | ||
| Rated input current(A) | 18 | ||
|
No-load voltage(V) |
268 | ||
| Output current adjustment range(A) | 20-80 | ||
| Rated output voltage(V) | 112 | ||
| Rated duty cycle(%) | 60 | ||
| No-load comsumption(W) | 60 | ||
| efficiency(%) | 85 | ||
| Power factor(cosφ) | 0.93 | ||
| Insulation class | F | ||
| Protechtion class | IP21S | ||
| Arc-start mode | Non-Contact | ||
| Gas Pressure(KG) | 4.5-5.5 | ||
| Cutting thickness(mm) | 1-28 | ||
| Weight(KG) | 25 | ||
| Demensions(mm) | 515*263*372 |
