FRITZ EMDE Co2 Refilling Unit

Co2 Refilling Unit

Chroma Gas Sdn Bhd
Type: Sale

Suitable to fill any size, shape of catridges, cylinder with universal filling head


Inquiry / Quote

To: Chroma Gas Sdn Bhd

Description

CO2-filling unit KU6 suitable to fill any size, shape or make of CO2-cartridges (from 20 g) and CO2-bottles (up to 6 kg) with the universal filling head. CO2-unit with integrated digital scale 30 kg in table form with 40 mm thick wooden board.


KU6-DI · KUD6-DI · KUS6-DI
No. 256 000 · No. 209 000 · No. 237 000



Optional available at extra charge:

  • Equipped with mechanical sliding weight scale
  • Electric supply with 230/400 V, 60 Hz
  • Equipped with label printer

The unit is equipped with:

  • Silent directly flanshed CO2-pump
  • Filling speed control for slow filling of cartridges and fast filling of large bottles
  • Fine regulation for small cartridges
  • Fast filling for large cylinders
  • Digital scale (30 kg weighing range) with automatic cutoff feature – resolution 5 g or 10 g optional
  • Operation by electrovalves
  • Filling of large bottles more than 6 kg has to be carried out on a separate floor scale with automatic cut-off feature (scale not included)
  • No pre-cooling system for CO2 source bottle required
  • Emptying of CO2 master bottle up to 95%
