Atlantic P Paintball
Yellow Jacket - IndustrialPressType: Sale
Small Size and big performance: It ‘s the most compact of the line Paintball, easy to transport to its low weight, allows refill even in hard to reach places, both the model Atlantic P Electric is the model with AtlanticG gasoline engine.
Description
Small Size and big performance: It ‘s the most compact of the line Paintball, easy to transport to its low weight, allows refill even in hard to reach places, both the model Atlantic P Electric is the model with AtlanticG gasoline engine.
Available in both Atlantic P Electric with single phase motor or Atlantic G Petrol with Subaru-Robin petrol engine.
Dual Pressure Model with 1 x 225 Bar Hose and 1 x 330 Bar Hose
• True Dual Pressure with Pressure Reducer
• Filling valve with Gauge and Depressurisation standard
• Powder Coated Aluminum frame
• Interstage Condensate Separator decreases the condensation between stages in a position well aerated to maintain low temperate
• Crankshaft perfectly balanced
• High quality materials resistant to thermal and dynamic stresses
• Air conveyor designed for high heat exchange efficiency
• Steel valves for longer life and greater performance
• Low noise and vibration due to perfect balance of the pump unit
• Reliable petrol motors designed and built by Subaru
• Automatic Condensate Drain Included
• Automatic Motor Stop Included (Final Pressure Switch)
Working Pressure: 200 Bar (2900 psi) & 300 Bar (4350 psi)
Safety Valve Pressure: 225 Bar (3260 psi) & 330 Bar (4780 psi)
Charging Rate (FAD): 100 lpm / 6m³h / 3.5 cfm
Filling Time: 20 minutes (10 litres / 200 bar)
No Of Stages: 4
Power Source: Subaru Robin EX17 Petrol Motor
Motor: 5.7 HP / 4.2 Kw / 2100 rpm
Fuel: Unleaded Petrol (3.6 litre tank)
Unit Dimensions: 760mm(L) x 370mm(W) x 430mm(H)
Packaged Dimensions: 790mm(L) x 400mm(W) x 470mm(H)
Weight: 40.0 kg
Noise: 84 dB
Max. Inclination Of Unit: 5°
Max Operating Altitude: 2000m (6560 ft)
Enclosure Rating: IP54
Compressor Oil Capacity: 0.35 Litres
Compressor Oil Type: Mineral 150 Viscosity
Fill Hoses: 2 x 1.0m Supplied (200 Bar & 300 Bar)
Fill Connections: DIN (Yoke Connections Available)
Available in both Atlantic P Electric with single phase motor or Atlantic G Petrol with Subaru-Robin petrol engine.
Dual Pressure Model with 1 x 225 Bar Hose and 1 x 330 Bar Hose
• True Dual Pressure with Pressure Reducer
• Filling valve with Gauge and Depressurisation standard
• Powder Coated Aluminum frame
• Interstage Condensate Separator decreases the condensation between stages in a position well aerated to maintain low temperate
• Crankshaft perfectly balanced
• High quality materials resistant to thermal and dynamic stresses
• Air conveyor designed for high heat exchange efficiency
• Steel valves for longer life and greater performance
• Low noise and vibration due to perfect balance of the pump unit
• Reliable petrol motors designed and built by Subaru
• Automatic Condensate Drain Included
• Automatic Motor Stop Included (Final Pressure Switch)
Working Pressure: 200 Bar (2900 psi) & 300 Bar (4350 psi)
Safety Valve Pressure: 225 Bar (3260 psi) & 330 Bar (4780 psi)
Charging Rate (FAD): 100 lpm / 6m³h / 3.5 cfm
Filling Time: 20 minutes (10 litres / 200 bar)
No Of Stages: 4
Power Source: Subaru Robin EX17 Petrol Motor
Motor: 5.7 HP / 4.2 Kw / 2100 rpm
Fuel: Unleaded Petrol (3.6 litre tank)
Unit Dimensions: 760mm(L) x 370mm(W) x 430mm(H)
Packaged Dimensions: 790mm(L) x 400mm(W) x 470mm(H)
Weight: 40.0 kg
Noise: 84 dB
Max. Inclination Of Unit: 5°
Max Operating Altitude: 2000m (6560 ft)
Enclosure Rating: IP54
Compressor Oil Capacity: 0.35 Litres
Compressor Oil Type: Mineral 150 Viscosity
Fill Hoses: 2 x 1.0m Supplied (200 Bar & 300 Bar)
Fill Connections: DIN (Yoke Connections Available)
